PRODUCT Outdoor LED Area Light

LED Area Light

MT Area Light With Photocell

The MT LED area light is a universal and scalable outdoor LED luminaire. The MT LED area light can be customized for virtually any type of outdoor lighting application by applying one of several different mounting options to a universal body to create an Area, Flood or Wall Pack luminaire. Four installation methods including Trunnion/Yoke, Slip fitter and Pole mount. The MT LED area light can be customized for standard on off wall switching, on/off motion sensor switching or multi-level motion sensor switching. The MT LED area light also comes standard with 1-10V dimming.

Document Library

MT FL221216-10.jpg
MT FL221216-04.jpg

Technical Information

Model number Voltage(V)Wattage(W)Replaces/Equiv.(MH)Dimming / ControlLumens(lm)CCT(K)CRIDistributionDimension(L"-W"-H")Finish/ColorIP RatingMaterialComplianceAverage life based on 104F(HRS)Order number
MT100401-PC-III 120-277 91 400W Photo control 13200 4000 >70 type III 24-13-4.75 Traditional Bronze IP66 aluminum DLC 70000 14956
MT100401-PC-IV 120-277 91 400W Photo control 13200 4000 >70 type IV 24-13-4.75 Traditional Bronze IP66 aluminum DLC 70000 14957
MT100401-PC-VW 120-277 91 400W Photo control 13200 4000 >70 type v wide 24-13-4.75 Traditional Bronze IP66 aluminum DLC 70000 14958
MT100401-PC-VN 120-277 91 400W Photo control 13200 4000 >70 type v narrow 24-13-4.75 Traditional Bronze IP66 aluminum DLC 70000 14959
MT100401-PC-VM 120-277 91 400W Photo control 13200 4000 >70 type v medium 24-13-4.75 Traditional Bronze IP66 aluminum DLC 70000 14960
MT100501-PC-III 120-277 91 400W Photo control 13200 5000 >70 type III 24-13-4.75 Traditional Bronze IP66 aluminum DLC 70000 14961
MT100501-PC-IV 120-277 91 400W Photo control 13200 5000 >70 type IV 24-13-4.75 Traditional Bronze IP66 aluminum DLC 70000 14962
MT100501-PC-VW 120-277 91 400W Photo control 13200 5000 >70 type v wide 24-13-4.75 Traditional Bronze IP66 aluminum DLC 70000 14963
MT100501-PC-VN 120-277 91 400W Photo control 13200 5000 >70 type v narrow 24-13-4.75 Traditional Bronze IP66 aluminum DLC 70000 14964
MT100501-PC-VM 120-277 91 400W Photo control 13200 5000 >70 type v medium 24-13-4.75 Traditional Bronze IP66 aluminum DLC 70000 14965
MT150401-PC-III 120-277 139 600W Photo control 18900 4000 >70 type III 24-13-4.75 Traditional Bronze IP66 aluminum DLC 70000 14966
MT150401-PC-IV 120-277 139 600W Photo control 18900 4000 >70 type IV 24-13-4.75 Traditional Bronze IP66 aluminum DLC 70000 14967
MT150401-PC-VW 120-277 139 600W Photo control 18900 4000 >70 type v wide 24-13-4.75 Traditional Bronze IP66 aluminum DLC 70000 14968
MT150401-PC-VN 120-277 139 600W Photo control 18900 4000 >70 type v narrow 24-13-4.75 Traditional Bronze IP66 aluminum DLC 70000 14969
MT150401-PC-VM 120-277 139 600W Photo control 18900 4000 >70 type v medium 24-13-4.75 Traditional Bronze IP66 aluminum DLC 70000 14970
MT150501-PC-III 120-277 139 600W Photo control 18900 5000 >70 type III 24-13-4.75 Traditional Bronze IP66 aluminum DLC 70000 14971
MT150501-PC-IV 120-277 139 600W Photo control 18900 5000 >70 type IV 24-13-4.75 Traditional Bronze IP66 aluminum DLC 70000 14972
MT150501-PC-VW 120-277 139 600W Photo control 18900 5000 >70 type v wide 24-13-4.75 Traditional Bronze IP66 aluminum DLC 70000 14973
MT150501-PC-VN 120-277 139 600W Photo control 18900 5000 >70 type v narrow 24-13-4.75 Traditional Bronze IP66 aluminum DLC 70000 14974
MT150501-PC-VM 120-277 139 600W Photo control 18900 5000 >70 type v medium 24-13-4.75 Traditional Bronze IP66 aluminum DLC 70000 14975
MT200401-PC-III 120-277 173 800W Photo control 21800 4000 >70 type III 24-13-4.75 Traditional Bronze IP66 aluminum DLC 70000 14976
MT200401-PC-IV 120-277 173 800W Photo control 21800 4000 >70 type IV 24-13-4.75 Traditional Bronze IP66 aluminum DLC 70000 14977
MT200401-PC-VW 120-277 173 800W Photo control 21800 4000 >70 type v wide 24-13-4.75 Traditional Bronze IP66 aluminum DLC 70000 14978
MT200401-PC-VN 120-277 173 800W Photo control 21800 4000 >70 type v narrow 24-13-4.75 Traditional Bronze IP66 aluminum DLC 70000 14979
MT200401-PC-VM 120-277 173 800W Photo control 21800 4000 >70 type v medium 24-13-4.75 Traditional Bronze IP66 aluminum DLC 70000 14980
MT200501-PC-III 120-277 173 800W Photo control 21800 5000 >70 type III 24-13-4.75 Traditional Bronze IP66 aluminum DLC 70000 14981
MT200501-PC-IV 120-277 173 800W Photo control 21800 5000 >70 type IV 24-13-4.75 Traditional Bronze IP66 aluminum DLC 70000 14982
MT200501-PC-VW 120-277 173 800W Photo control 21800 5000 >70 type v wide 24-13-4.75 Traditional Bronze IP66 aluminum DLC 70000 14983
MT200501-PC-VN 120-277 173 800W Photo control 21800 5000 >70 type v narrow 24-13-4.75 Traditional Bronze IP66 aluminum DLC 70000 14984
MT200501-PC-VM 120-277 173 800W Photo control 21800 5000 >70 type v medium 24-13-4.75 Traditional Bronze IP66 aluminum DLC 70000 14985
