The VERSATILE series has the high-performance solution for the most demanding applications with an universal body and different shades. It can be used in many applications such as pedestrian street, factory, schools, garden, courtyard, hotel, parking lot, public parks etc.
| Spec Sheet | Versatile Area Light Spec Sheet |
|---|---|
| Instruction Manual | Versatile Area Light Instruction Manual |
| Motion Sensor | Programmable Multi-Level Motion Sensor Instruction Manual |
| Photocontrols | 120-277VAC/480VAC Photocontrols |
| Motion Sensor | Low Voltage Microwave Bi-level Sensor |
| IES | Versatile Area Light IES |
| Catalog | Versatile Area Light Catalog |
| How Are We Different | Versatile Area Light PPT |
| Tech Info | Versatile Area Light Tech Info |
| Revit file | Please email info@abovealllighting.com for Revit file |
| Video | Versatile Area Light Video |
| Model number | Voltage(V) | Wattage(W) | Replaces/Equiv.(MH) | Controls | Lumens(lm) | CCT(K) | CRI | Distribution | Dimension(Horizontal arm) | Finish/Color | IP Rating | Material | Compliance | Average life based on 104F(HRS) | Order number |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| VPTD30401-T5 | 120-277 | 30 | 150W | Available | 4060 | 4000 | 70 | Type VN | 27 3/16"-19 3/16"-2 3/8" | Bronze | 66 | Aluminium | UL | 50000 | 14325 |
| VPTD60401-T5 | 120-277 | 60 | 175W | Available | 8200 | 4000 | 70 | Type VN | 27 3/16"-19 3/16"-2 3/8" | Bronze | 66 | Aluminium | UL | 50000 | 14326 |
| VPTD90401-T5 | 120-277 | 90 | 250W | Available | 12000 | 4000 | 70 | Type VN | 27 3/16"-19 3/16"-2 3/8" | Bronze | 66 | Aluminium | UL | 50000 | 14327 |
| VPTD150401-T5 | 120-277 | 150 | 320W | Available | 18700 | 4000 | 70 | Type VN | 27 3/16"-19 3/16"-2 3/8" | Bronze | 66 | Aluminium | UL | 50000 | 14328 |
