The VERSATILE series has the high-performance solution for the most demanding applications with an universal body and different shades. It can be used in many applications such as pedestrian street, factory, schools, garden, courtyard, hotel, parking lot, public parks etc.
| Spec Sheet | Versatile Post Top Spec Sheet |
|---|---|
| Instruction Manual | Versatile Post Top Instruction Manual |
| IES Files | Versatile Post Top IES Files |
| Photocontrols | 120-277VAC/480VAC Photocontrols |
| Motion Sensor | Programmable Multi-Level Motion Sensor Instruction Manual |
| Catalog | Versatile Post Top Catalog |
| Motion Sensor | Low Voltage Microwave Bi-level Sensor |
| How Are We Different | Versatile Post Top PPT |
| Spec Sheet | Please email info@abovealllighting.com for Revit file |
| Tech Info | Versatile Post Top Tech Info |
| Video | Versatile Post Top Video |
| Model number | Voltage(V) | Wattage(W) | Replaces/Equiv.(MH) | Controls | Lumens(lm) | CCT(K) | CRI | Distribution | Dimension(D"-H") | Finish/Color | IP Rating | Material | Compliance | Average life based on 104F(HRS) | Order number |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| VPTB30401-T5 | 120-277 | 30 | 150W | Available | 4060 | 4000 | 70 | Type VN | Φ19 1/16" -18 15/16" | Bronze | 66 | Aluminium | UL | 50000 | 14312 |
| VPTB60401-T5 | 120-277 | 60 | 175W | Available | 8200 | 4000 | 70 | Type VN | Φ19 1/16" -18 15/16" | Bronze | 66 | Aluminium | UL | 50000 | 14313 |
| VPTB90401-T5 | 120-277 | 90 | 250W | Available | 12000 | 4000 | 70 | Type VN | Φ19 1/16" -18 15/16" | Bronze | 66 | Aluminium | UL | 50000 | 14314 |
| VPTB150401-T5 | 120-277 | 150 | 320W | Available | 18700 | 4000 | 70 | Type VN | Φ19 1/16" -18 15/16" | Bronze | 66 | Aluminium | UL | 50000 | 14315 |
