The Slim Focus Round Light offers three sizes. Edge-lit technology and non-yellowing optical PMMA light guide plate. Whether configured for pendant mounted or surface mounted applications, it is perfect in conference rooms, open offices, retail settings, or anywhereyou want to make a statement.
| Spec Sheet | Slim Focus Round Light Spec Sheet |
|---|---|
| IES | Slim Focus Round Light IES |
| Brochure | Slim Focus Round Light Brochure |
| Tech Info | Slim Focus Round Light Tech Info |
| Model number | Voltage(V) | Wattage(W) | Replaces/Equiv.(MH) | Controls | Lumens(lm) | CCT(K) | CRI | Distribution | Dimension | Finish/Color | IP Rating | Material | Compliance | Average life based on 104F(HRS) | Order number |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| SFRD16-25-SW801-SMK-WH | 120-277 | 25 | / | 0-10V Dim | 2600 | 4000 | 80 | / | 15.7" | White | 20 | PMMA+aluminum | ETL | 50000 | 16799 |
| SFRD16-25-SW801-ACPMK-WH | 120-277 | 25 | / | 0-10V Dim | 2600 | 4000 | 80 | / | 15.7" | White | 20 | PMMA+aluminum | ETL | 50000 | 16808 |
| SFRD20-32-SW801-SMK-WH | 120-277 | 32 | / | 0-10V Dim | 3680 | 4000 | 80 | / | 19.7" | White | 20 | PMMA+aluminum | ETL | 50000 | 16809 |
| SFRD20-32-SW801-ACPMK-WH | 120-277 | 32 | / | 0-10V Dim | 3680 | 4000 | 80 | / | 19.7" | White | 20 | PMMA+aluminum | ETL | 50000 | 16810 |
| SFRD24-36-SW801-SMK-WH | 120-277 | 36 | / | 0-10V Dim | 4200 | 4000 | 80 | / | 23.6" | White | 20 | PMMA+aluminum | ETL | 50000 | 16811 |
| SFRD24-36-SW801-ACPMK-WH | 120-277 | 36 | / | 0-10V Dim | 4200 | 4000 | 80 | / | 23.6" | White | 20 | PMMA+aluminum | ETL | 50000 | 16812 |
