PRODUCT Outdoor LED Area Light

LED Area Light

MT Area Light With 7 Pin Receptacle

The MT LED area light is a universal and scalable outdoor LED luminaire. The MT LED area light can be customized for virtually any type of outdoor lighting application by applying one of several different mounting options to a universal body to create an Area, Flood or Wall Pack luminaire. Four installation methods including Trunnion/Yoke, Slip fitter and Pole mount. The MT LED area light can be customized for standard on off wall switching, on/off motion sensor switching or multi-level motion sensor switching. The MT LED area light also comes standard with 1-10V dimming.

Document Library

MT FL221216-10.jpg
MT FL221216-04.jpg

Technical Information

Model number Voltage(V)Wattage(W)Replaces/Equiv.(MH)Dimming / ControlLumens(lm)CCT(K)CRIDistributionDimension(L"-W"-H")Finish/ColorIP RatingMaterialComplianceAverage life based on 104F(HRS)Order number
MT100401-7P-III 120-277 91 400W 7 Pin PE receptacle 13200 4000 >70 type III 24-13-4.75 Traditional Bronze IP66 aluminum DLC 70000 14986
MT100401-7P-IV 120-277 91 400W 7 Pin PE receptacle 13200 4000 >70 type IV 24-13-4.75 Traditional Bronze IP66 aluminum DLC 70000 14987
MT100401-7P-VW 120-277 91 400W 7 Pin PE receptacle 13200 4000 >70 type v wide 24-13-4.75 Traditional Bronze IP66 aluminum DLC 70000 14988
MT100401-7P-VN 120-277 91 400W 7 Pin PE receptacle 13200 4000 >70 type v narrow 24-13-4.75 Traditional Bronze IP66 aluminum DLC 70000 14989
MT100401-7P-VM 120-277 91 400W 7 Pin PE receptacle 13200 4000 >70 type v medium 24-13-4.75 Traditional Bronze IP66 aluminum DLC 70000 14990
MT100501-7P-III 120-277 91 400W 7 Pin PE receptacle 13200 5000 >70 type III 24-13-4.75 Traditional Bronze IP66 aluminum DLC 70000 14991
MT100501-7P-IV 120-277 91 400W 7 Pin PE receptacle 13200 5000 >70 type IV 24-13-4.75 Traditional Bronze IP66 aluminum DLC 70000 14992
MT100501-7P-VW 120-277 91 400W 7 Pin PE receptacle 13200 5000 >70 type v wide 24-13-4.75 Traditional Bronze IP66 aluminum DLC 70000 14993
MT100501-7P-VN 120-277 91 400W 7 Pin PE receptacle 13200 5000 >70 type v narrow 24-13-4.75 Traditional Bronze IP66 aluminum DLC 70000 14994
MT100501-7P-VM 120-277 91 400W 7 Pin PE receptacle 13200 5000 >70 type v medium 24-13-4.75 Traditional Bronze IP66 aluminum DLC 70000 14995
MT150401-7P-III 120-277 139 600W 7 Pin PE receptacle 18900 4000 >70 type III 24-13-4.75 Traditional Bronze IP66 aluminum DLC 70000 14996
MT150401-7P-IV 120-277 139 600W 7 Pin PE receptacle 18900 4000 >70 type IV 24-13-4.75 Traditional Bronze IP66 aluminum DLC 70000 14997
MT150401-7P-VW 120-277 139 600W 7 Pin PE receptacle 18900 4000 >70 type v wide 24-13-4.75 Traditional Bronze IP66 aluminum DLC 70000 14998
MT150401-7P-VN 120-277 139 600W 7 Pin PE receptacle 18900 4000 >70 type v narrow 24-13-4.75 Traditional Bronze IP66 aluminum DLC 70000 14999
MT150401-7P-VM 120-277 139 600W 7 Pin PE receptacle 18900 4000 >70 type v medium 24-13-4.75 Traditional Bronze IP66 aluminum DLC 70000 15000
MT150501-7P-III 120-277 139 600W 7 Pin PE receptacle 18900 5000 >70 type III 24-13-4.75 Traditional Bronze IP66 aluminum DLC 70000 15001
MT150501-7P-IV 120-277 139 600W 7 Pin PE receptacle 18900 5000 >70 type IV 24-13-4.75 Traditional Bronze IP66 aluminum DLC 70000 15002
MT150501-7P-VW 120-277 139 600W 7 Pin PE receptacle 18900 5000 >70 type v wide 24-13-4.75 Traditional Bronze IP66 aluminum DLC 70000 15003
MT150501-7P-VN 120-277 139 600W 7 Pin PE receptacle 18900 5000 >70 type v narrow 24-13-4.75 Traditional Bronze IP66 aluminum DLC 70000 15004
MT150501-7P-VM 120-277 139 600W 7 Pin PE receptacle 18900 5000 >70 type v medium 24-13-4.75 Traditional Bronze IP66 aluminum DLC 70000 15005
MT200401-7P-III 120-277 173 800W 7 Pin PE receptacle 21800 4000 >70 type III 24-13-4.75 Traditional Bronze IP66 aluminum DLC 70000 15006
MT200401-7P-IV 120-277 173 800W 7 Pin PE receptacle 21800 4000 >70 type IV 24-13-4.75 Traditional Bronze IP66 aluminum DLC 70000 15007
MT200401-7P-VW 120-277 173 800W 7 Pin PE receptacle 21800 4000 >70 type v wide 24-13-4.75 Traditional Bronze IP66 aluminum DLC 70000 15008
MT200401-7P-VN 120-277 173 800W 7 Pin PE receptacle 21800 4000 >70 type v narrow 24-13-4.75 Traditional Bronze IP66 aluminum DLC 70000 15009
MT200401-7P-VM 120-277 173 800W 7 Pin PE receptacle 21800 4000 >70 type v medium 24-13-4.75 Traditional Bronze IP66 aluminum DLC 70000 15010
MT200501-7P-III 120-277 173 800W 7 Pin PE receptacle 21800 5000 >70 type III 24-13-4.75 Traditional Bronze IP66 aluminum DLC 70000 15011
MT200501-7P-IV 120-277 173 800W 7 Pin PE receptacle 21800 5000 >70 type IV 24-13-4.75 Traditional Bronze IP66 aluminum DLC 70000 15012
MT200501-7P-VW 120-277 173 800W 7 Pin PE receptacle 21800 5000 >70 type v wide 24-13-4.75 Traditional Bronze IP66 aluminum DLC 70000 15013
MT200501-7P-VN 120-277 173 800W 7 Pin PE receptacle 21800 5000 >70 type v narrow 24-13-4.75 Traditional Bronze IP66 aluminum DLC 70000 15014
MT200501-7P-VM 120-277 173 800W 7 Pin PE receptacle 21800 5000 >70 type v medium 24-13-4.75 Traditional Bronze IP66 aluminum DLC 70000 15015
