The Boon led canopy has an elegant and compact design. Aluminum alloy housing and polycarbonate optical lens. It is well designed for superior illumination performance in exterior ceiling mount and canopy applications. 3000/4000/5000K selectable and power selectable. The Boon has uplight as standard, which effectively reduces "cave" effect. Plug-and-play sensor and emergency battery backup available to reduce energy demand and cost.
| Spec Sheet | Boon LED Canopy Light Spec Sheet |
|---|---|
| IES | Boon LED Canopy Light IES |
| Tech Info | Boon LED Canopy Light Tech Info |
| Model number | Voltage(V) | Wattage(W) | Replaces/Equiv.(MH) | Dimming / Control | Lumens(lm) | CCT(K) | CRI | Distribution | Dimension(D"-H") | Finish/Color | IP Rating | Material | Compliance | Average life based on 104F(HRS) | Order number |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| BOCAN-60SP-SW8-WH | 120-347 | 60W selectable | 200W | Available | 9400 | 3000K/4000K/5000K | 70 | / | Φ10.7"-3" | White | 65 | Aluminium | ETL | 50000 | 17102 |
| BOCAN-100SP-SW8-WH | 120-347 | 100W selectable | 400W | Available | 15700 | 3000K/4000K/5000K | 70 | / | Φ12.7"-3.3" | White | 65 | Aluminium | ETL | 50000 | 17103 |
