LED V-line Wall pack are designed with a high quality die cast housing. Durable chip and fade resistant powder coat finish. Efficient design separates the driver from the LED to minimize heat, air cooling design of aerodynamic and modern appearance. Adjustable head for precise aiming.
| Spec Sheet | V-Line Wall Pack Spec Sheet |
|---|---|
| Instruction Manual | V-Line Wall Pack Manual |
| IES Files | V-Line Wall Pack IES Files |
| Motion Sensor | Programmable Multi-Level Motion Sensor Instruction Manual |
| How Are We Different | V-Line Wall Pack PPT |
| Brochure | V-Line Wall Pack Brochure |
| Tech Info | V-Line Wall Pack Tech Info |
| Video | V-Line Wall Pack Video |
| Revit file | Please email info@abovealllighting.com for Revit file |
| Model number | Voltage(V) | Wattage(W) | Replaces/Equiv.(MH) | Dimming / Control | Lumens(lm) | CCT(K) | CRI | Beam Angle(Degree) | Dimension(L"-W"-H") | Finish/Color | IP Rating | Material | Compliance | Average life based on 104F(HRS) | Order number |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| WL26501 | 120-277 | 26 | 150W | Available | 3860 | 5000 | >70 | 80 | 10.12-9.84-4.69 | Traditional Bronze | 66 | Aluminum | DLC Premium | 50000 | 10291A |
| WL26401 | 120-277 | 26 | 150W | Available | 3860 | 4000 | >70 | 80 | 10.12-9.84-4.69 | Traditional Bronze | 66 | Aluminum | DLC Premium | 50000 | 11234A |
| WL26301 | 120-277 | 26 | 150W | Available | 3550 | 3000 | >70 | 80 | 10.12-9.84-4.69 | Traditional Bronze | 66 | Aluminum | DLC Premium | 50000 | 11803A |
| WL38501 | 120-277 | 38 | 175w | Available | 5740 | 5000 | >70 | 80 | 10.12-9.84-4.69 | Traditional Bronze | 66 | Aluminum | DLC Premium | 50000 | 10296A |
| WL38401 | 120-277 | 38 | 175w | Available | 5740 | 4000 | >70 | 80 | 10.12-9.84-4.69 | Traditional Bronze | 66 | Aluminum | DLC Premium | 50000 | 11586A |
| WL38301 | 120-277 | 38 | 175w | Available | 5280 | 3000 | >70 | 80 | 10.12-9.84-4.69 | Traditional Bronze | 66 | Aluminum | DLC Premium | 50000 | 12587A |
| WL52501 | 120-277 | 52 | 250W | Available | 7780 | 5000 | >70 | 90 | 15.32-13.78-4.4 | Traditional Bronze | 66 | Aluminum | DLC Premium | 50000 | 10301A |
| WL52401 | 120-277 | 52 | 250W | Available | 7780 | 4000 | >70 | 90 | 15.32-13.78-4.4 | Traditional Bronze | 66 | Aluminum | DLC Premium | 50000 | 11557A |
| WL52301 | 120-277 | 52 | 250W | Available | 7160 | 3000 | >70 | 90 | 15.32-13.78-4.4 | Traditional Bronze | 66 | Aluminum | DLC Premium | 50000 | 11556A |
| WL70501 | 120-277 | 80 | 320W | Available | 11240 | 5000 | >70 | 90 | 15.32-13.78-4.4 | Traditional Bronze | 66 | Aluminum | DLC Premium | 50000 | 10324A |
| WL70401 | 120-277 | 80 | 320W | Available | 11240 | 4000 | >70 | 90 | 15.32-13.78-4.4 | Traditional Bronze | 66 | Aluminum | DLC Premium | 50000 | 11576A |
| WL70301 | 120-277 | 80 | 320W | Available | 10340 | 3000 | >70 | 90 | 15.32-13.78-4.4 | Traditional Bronze | 66 | Aluminum | DLC Premium | 50000 | 12594A |
| WL100501 | 120-277 | 100 | 400W | Available | 15000 | 5000 | >70 | 90 | 15.32-13.78-4.4 | Traditional Bronze | 66 | Aluminum | DLC Premium | 50000 | 10741A |
| WL100401 | 120-277 | 100 | 400W | Available | 15000 | 4000 | >70 | 90 | 15.32-13.78-4.4 | Traditional Bronze | 66 | Aluminum | DLC Premium | 50000 | 11587A |
| WL100301 | 120-277 | 100 | 400W | Available | 13800 | 3000 | >70 | 90 | 15.32-13.78-4.4 | Traditional Bronze | 66 | Aluminum | DLC Premium | 50000 | 15188A |
| WL120501 | 120-277 | 120 | 400W | Available | 17000 | 5000 | >70 | 90 | 15.32-13.78-4.4 | Traditional Bronze | 66 | Aluminum | DLC Premium | 50000 | 12922A |
| WL120401 | 120-277 | 120 | 400W | Available | 17000 | 4000 | >70 | 90 | 15.32-13.78-4.4 | Traditional Bronze | 66 | Aluminum | DLC Premium | 50000 | 12923A |
| WL120301 | 120-277 | 120 | 400W | Available | 15640 | 3000 | >70 | 90 | 15.32-13.78-4.4 | Traditional Bronze | 66 | Aluminum | DLC Premium | 50000 | 15189A |
