The NOVA LED commercial downlights are available in 4", 6", 8" and 10" with up to 40W. The integral junction box and choice of trim feature, adds to the flexibility of this downlight. Butterfly clips make for easy-fit installation whether new construction or retrofit. The integral junction box eliminates the need for a traditional recessed housing and the complete fixture mounts directly into the ceiling. It is suitable for commercial and public places and elegantly decorates the ambience, such as shopping mall,hospital, airport, hotel lobby etc.
| Model number | Voltage(V) | Wattage (W) | Replaces/Equiv.(FL) | Dimming/Control | Lumens(lm) | CCT(K) | CRI | Distribution | Dimension(L"-W"-H") | Finish/Color | IP Rating | Material | Compliance | Average life based on 104F(HRS) | Order number |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| NOVA-20SPSW8 | 120-347 | 20W selectable | / | 1-10V Dim | 1500 | 3000K/3500K/4000K | 80 | / | 4.14"-3.46" | Silver | 20 | Aluminum | UL | 50000 | 18150 |
| NOVA-40SPSW8 | 120-347 | 40W selectable | / | 1-10V Dim | 3200 | 3000K/3500K/4000K | 80 | / | 4.14"-4.96" | Silver | 20 | Aluminum | UL | 50000 | 18151 |
