The Cone LED Post Top is supplied with a cast aluminum roof which includes optimized heat sinks, maximizing the life and performance of the LED light sources. Optical design, greatly improves the light efficiency and uniformity. It can be widely used for outdoor lighting applications such as landscape, courtyards, roadways.
| Spec Sheet | Cone LED Post Top Spec Sheet |
|---|---|
| Instruction Manual | Cone LED Post Top Instruction Manual |
| IES | Cone LED Post Top IES |
| Revit file | Please email info@abovealllighting.com for Revit file |
| Tech Info | Cone LED Post Top Tech Info |
| Model number | Voltage(V) | Wattage(W) | Replaces/Equiv.(MH) | Controls | Lumens(lm) | CCT(K) | CRI | Distribution | Dimension | Finish/Color | IP Rating | Material | Compliance | Average life based on 104F(HRS) | Order number |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| CPT60401-V-BK | 120-277 | 60 | 250W | N/A | 8000 | 4000 | 70 | V | Φ18.9"-18.8" | Bronze | 65 | Aluminum | UL | 50000 | 15877 |
| CPT100401-V-BK | 120-277 | 100 | 400W | N/A | 13200 | 4000 | 70 | V | Φ18.9"-18.8" | Bronze | 65 | Aluminum | UL | 50000 | 15878 |
