PRODUCT Indoor LED Downlight

LED Downlight

4 in PORLA LED Downlight 2000LM - Square

This 4" Porla recessed led downlight is powered by high efficiency LED chips and external LED driver. Round and square shapes with integral driver in a remote driver box. Five CCT selectable. Flexibility to switch color temperature during installation with the slide switch located on the cable. Reflector optic design. Ideal for a variety of applications for both residential and commercial settings.

Document Library

4in 15002000 DL-03.jpg
4in 15002000 DL-07.jpg
2%22 ADJ-04.jpg

Technical Information

Model number Voltage(V)Wattage (W)Replaces/Equiv.(FL)Dimming/ControlLumens(lm)CCT(K)CRIDistributionDimension(L"-W"-H")Finish/ColorIP RatingMaterialComplianceAverage life based on 104F(HRS)Order number
POR04-DLR-15LM-90-MBK / 18 75W incandescent / 1500 2700/3000/3500/4000/5000 90 38 degree Ø4 1/2"- 4 3/4" White Damp Location Alumilum ETL 50000 90813**
POR04-DLR-15LM-90-MWH / 18 75W incandescent / 1500 2700/3000/3500/4000/5000 90 38 degree Ø4 1/2"- 4 3/4" White Damp Location Alumilum ETL 50000 90842**
POR04-DLS-15LM-90-MBK / 18 75W incandescent / 1500 2700/3000/3500/4000/5000 90 38 degree Ø4 1/2"- 4 3/4" White Damp Location Alumilum ETL 50000 90843**
POR04-DLS-15LM-90-MWH / 18 75W incandescent / 1500 2700/3000/3500/4000/5000 90 38 degree Ø4 1/2"- 4 3/4" White Damp Location Alumilum ETL 50000 90844**
POR04-18W-4 120 18 / Triac dimming / / / / / / Damp Location Alumilum ETL 50000 90783**
POR04-18W-1 120-277 18 / 0-10V dimming / / / / / / Damp Location Alumilum ETL 50000 90822**
POR04-DLR-20LM-90-MBK / 25 100W HID / 2000 2700/3000/3500/4000/5000 90 38 degree Ø4 1/2"- 4 3/4" White Damp Location Alumilum ETL 50000 90814**
POR04-DLR-20LM-90-MWH / 25 100W HID / 2000 2700/3000/3500/4000/5000 90 38 degree Ø4 1/2"- 4 3/4" White Damp Location Alumilum ETL 50000 90845**
POR04-DLS-20LM-90-MBK / 25 100W HID / 2000 2700/3000/3500/4000/5000 90 38 degree Ø4 1/2"- 4 3/4" White Damp Location Alumilum ETL 50000 90846**
POR04-DLS-20LM-90-MWH / 25 100W HID / 2000 2700/3000/3500/4000/5000 90 38 degree Ø4 1/2"- 4 3/4" White Damp Location Alumilum ETL 50000 90847**
POR04-25W-4 120 25 / Triac dimming / / / / / / Damp Location Alumilum ETL 50000 90820**
POR04-25W-1 120-277 25 / 0-10V dimming / / / / / / Damp Location Alumilum ETL 50000 90823**
