The Galene Wall Light is designed in a round or square shape with durable powder coat paint. It combines aluminum structure with a tempered glass diffuser radiating light upward and downward against the wall where installed.
| Spec Sheet | Galene Square Wall Light Spec Sheet |
|---|---|
| Instruction Manual | Galene Square Wall Light Instruction Manual |
| IES | Galene Square Wall Light Light IES |
| Tech Info | Galene Square Wall Light Light Tech Info |
| Revit file | Please email info@abovealllighting.com for Revit file |
| Model number | Voltage(V) | Wattage(W) | Replaces/Equiv.(MH) | Controls | Lumens(lm) | CCT(K) | CRI | Distribution | Dimension | Finish/Color | IP Rating | Material | Compliance | Average life based on 104F(HRS) | Order number |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| GID-RSP-SW8-45-BK | 120-347 | 20/40 | 100W | N/A | 2400/4800lm | 3000K/4000K/5000K | 70 | 45° | 13.62"-Φ5.51" | Black | 65 | Aluminum | UL | 50000 | 15784 |
| GID-RSP-SW8-60-BK | 120-347 | 20/40 | 100W | N/A | 2400/4800lm | 3000K/4000K/5000K | 70 | 60° | 13.62"-Φ5.51" | Black | 65 | Aluminum | UL | 50000 | 15805 |
| GID-SSP-SW8-45-BK | 120-347 | 20/40 | 100W | N/A | 2400/4800lm | 3000K/4000K/5000K | 70 | 45° | 13.62"-Φ5.91" | Black | 65 | Aluminum | UL | 50000 | 15808 |
| GID-SSP-SW8-60-BK | 120-347 | 20/40 | 100W | N/A | 2400/4800lm | 3000K/4000K/5000K | 70 | 60° | 13.62"-Φ5.91" | Black | 65 | Aluminum | UL | 50000 | 15809 |
| GID-RSP-SW8-25-BK | 120-347 | 20/40 | 100W | N/A | 2400/4800lm | 3000K/4000K/5000K | 70 | 25° | 13.62"-Φ5.51" | Black | 65 | Aluminum | UL | 50000 | 16337 |
| GID-SSP-SW8-25-BK | 120-347 | 20/40 | 100W | N/A | 2400/4800lm | 3000K/4000K/5000K | 70 | 25° | 13.62"-Φ5.91" | Black | 65 | Aluminum | UL | 50000 | 16338 |
